LiteLLM Router Setup: Fallback, Cost Routing & Model Pools

Your LLM provider just returned a 429. Your app is down. Your users are angry.

That's the exact problem the LiteLLM Router solves - and it does it in fewer than 20 lines of Python. With 51,000+ GitHub stars on BerriAI/litellm and adoption at Stripe, Netflix, and Google ADK, it's become the default reliability layer for production LLM applications.

This guide covers everything: model pools, all six routing strategies, three fallback types, cost-based routing, routing groups, and the production settings that actually matter.

---

TL;DR

• Install with pip install litellm
• Define a model_list with multiple deployments under the same model_name alias
• Use simple-shuffle (default) for most cases - it's the fastest
• Add fallbacks, context_window_fallbacks, and content_policy_fallbacks for resilience
• Use cost-based-routing when mixing GPT-4o with cheaper models like Claude Haiku or Gemini Flash
• Add Redis for distributed deployments tracking cooldowns and TPM/RPM across instances

---

What Is the LiteLLM Router?

LiteLLM is an open-source Python library that gives you a single, unified interface to call 100+ LLM providers - OpenAI, Anthropic, Azure, Bedrock, Gemini, Groq, and more - using the OpenAI format.

The LiteLLM Router is its production-grade load balancing layer. It sits in front of your model deployments and handles:

• LiteLLM load balancing across multiple deployments of the same model
• LiteLLM fallback chains that trigger automatically on failure
• Retries with fixed and exponential backoff
• Cost tracking and LiteLLM cost routing to the cheapest available deployment
• Cooldowns that isolate failing deployments without taking down the whole model group

The router lives at litellm/router.py and is used as a Python SDK or behind the LiteLLM Proxy Server. This is load balancing across deployments of the same model - a different job from semantic routing as the decision layer, which picks which model handles a query based on its meaning.

---

Quick Setup: Your First Router in 5 Minutes

Install the library:

pip install litellm

Here's a working router with two deployments - one Azure, one OpenAI - both aliased under "gpt-3.5-turbo":

import os
from litellm import Router

model_list = [
    {
        "model_name": "gpt-3.5-turbo",       # model alias (what you call in your code)
        "litellm_params": {
            "model": "azure/chatgpt-v-2",     # actual model name
            "api_key": os.getenv("AZURE_API_KEY"),
            "api_version": os.getenv("AZURE_API_VERSION"),
            "api_base": os.getenv("AZURE_API_BASE"),
        },
    },
    {
        "model_name": "gpt-3.5-turbo",
        "litellm_params": {
            "model": "gpt-3.5-turbo",         # OpenAI direct
            "api_key": os.getenv("OPENAI_API_KEY"),
        },
    },
]

router = Router(model_list=model_list)

response = router.completion(
    model="gpt-3.5-turbo",
    messages=[{"role": "user", "content": "Hey, how's it going?"}],
)
print(response)

Key fields in litellm_params:

• model - the actual provider model string (e.g., "azure/chatgpt-v-2", "gpt-3.5-turbo")
• api_key - provider API key
• api_base - endpoint URL (required for Azure)
• api_version - API version string (Azure-specific)

That's it. Every call to router.completion(model="gpt-3.5-turbo", ...) will now load-balance across both deployments automatically.

---

Model Pools: How to Group and Manage Deployments

A model pool is just multiple deployments sharing the same model_name alias. The router treats them as a single logical model and picks between them based on your routing strategy.

Here's a pool of three deployments under one alias, with weights and rate limits:

import os
from litellm import Router

model_list = [
    {
        "model_name": "gpt-3.5-turbo",
        "litellm_params": {
            "model": "azure/chatgpt-v-2",
            "api_key": os.getenv("AZURE_API_KEY"),
            "api_version": os.getenv("AZURE_API_VERSION"),
            "api_base": os.getenv("AZURE_API_BASE"),
            "weight": 9,       # ~90% of traffic
            "rpm": 900,        # requests per minute limit
            "tpm": 100000,     # tokens per minute limit
        },
    },
    {
        "model_name": "gpt-3.5-turbo",
        "litellm_params": {
            "model": "azure/chatgpt-functioncalling",
            "api_key": os.getenv("AZURE_API_KEY"),
            "api_version": os.getenv("AZURE_API_VERSION"),
            "api_base": os.getenv("AZURE_API_BASE"),
            "weight": 1,       # ~10% of traffic
            "rpm": 100,
        },
    },
    {
        "model_name": "gpt-3.5-turbo",
        "litellm_params": {
            "model": "gpt-3.5-turbo",
            "api_key": os.getenv("OPENAI_API_KEY"),
            "order": 2,        # lower priority - used as last resort in pool
            "rpm": 1000,
        },
    },
]

router = Router(model_list=model_list, routing_strategy="simple-shuffle")

Three parameters that control pool behavior:

• weight - relative pick frequency. weight: 9 on one deployment and weight: 1 on another means ~90%/10% split.
• rpm / tpm - rate limits per deployment. The router uses these to avoid overloading any single endpoint.
• order - priority within the pool. order: 1 is tried first; order: 2 is tried only when order: 1 fails or is on cooldown.

---

Routing Strategies: Which One Should You Use?

The default simple-shuffle works for most teams. Here's when to switch.

These strategies all balance load within a model group; choosing between models of different capability is a separate decision - see our RouteLLM vs semantic-router comparison.

Set your strategy at router initialization:

router = Router(model_list=model_list, routing_strategy="latency-based-routing")

Strategy comparison

Strategy	How It Works	Best For	Pros	Cons
simple-shuffle (default)	Random pick, weighted by rpm/weight	General purpose, high throughput	Minimal latency overhead, no state	Doesn't optimize for latency or cost
least-busy	Routes to deployment with fewest active requests	High-concurrency scenarios	Prevents overload on any single deployment	Slight overhead for request tracking
latency-based-routing	Routes to deployment with lowest cached response time	Latency-critical user-facing apps	Optimizes speed over time	Initial overhead; needs warm-up calls
usage-based-routing	Routes to deployment with lowest current TPM usage	Strict rate-limit compliance	Respects limits evenly	Not recommended for production - adds significant Redis latency
cost-based-routing	Routes to deployment with lowest cost per token	Mixed-model pools (e.g., GPT-4o + Groq)	Automatic cost minimization	Async only; unknown cost for unrecognized models
weighted-pick	RPM/TPM-aware distribution using weight param	Controlled traffic splits	Predictable distribution	Manual weight management

Warning: The LiteLLM docs explicitly flag usage-based-routing as bad for production performance due to Redis overhead on every request. Stick to simple-shuffle unless you have a specific reason to switch.

For latency-based-routing, you can tune the time window and add a buffer to prevent one fast deployment from absorbing all traffic:

router = Router(
    model_list=model_list,
    routing_strategy="latency-based-routing",
    routing_strategy_args={
        "ttl": 3600,                  # latency window in seconds
        "lowest_latency_buffer": 0.5, # consider deployments within 50% of the fastest
    },
)

---

Fallback Configuration: Never Let a Failed Model Break Your App

Fallbacks let you define a backup model chain that triggers automatically when the primary fails. After num_retries are exhausted on the primary, the router moves to the next model in the fallback list - in order.

The three fallback types

LiteLLM has three distinct fallback parameters, each targeting a different error class:

• fallbacks - catches general errors: 429 rate limits, 500 server errors, connection failures
• content_policy_fallbacks - catches ContentPolicyViolationError specifically
• context_window_fallbacks - catches ContextWindowExceededError when input tokens exceed the model's limit

Critical rule: Every model referenced in a fallback must also exist in model_list. If it's missing, the router raises a BadRequestError.

Python SDK example

import os
from litellm import Router

model_list = [
    {
        "model_name": "gpt-3.5-turbo",
        "litellm_params": {
            "model": "azure/chatgpt-v-2",
            "api_key": os.getenv("AZURE_API_KEY"),
            "api_version": os.getenv("AZURE_API_VERSION"),
            "api_base": os.getenv("AZURE_API_BASE"),
            "rpm": 6,
        },
    },
    {
        "model_name": "gpt-4",
        "litellm_params": {
            "model": "azure/gpt-4-ca",
            "api_base": "https://my-endpoint-canada-berri992.openai.azure.com/",
            "api_key": os.getenv("AZURE_API_KEY"),
            "rpm": 6,
        },
    },
    {
        "model_name": "gpt-4-large-context",
        "litellm_params": {
            "model": "gpt-4-turbo",
            "api_key": os.getenv("OPENAI_API_KEY"),
        },
    },
]

router = Router(
    model_list=model_list,
    fallbacks=[{"gpt-3.5-turbo": ["gpt-4"]}],               # general errors
    context_window_fallbacks=[{"gpt-3.5-turbo": ["gpt-4-large-context"]}],
    num_retries=3,
)

response = router.completion(
    model="gpt-3.5-turbo",
    messages=[{"role": "user", "content": "Hello!"}],
)

Proxy YAML config example

model_list:
  - model_name: gpt-3.5-turbo
    litellm_params:
      model: azure/chatgpt-v-2
      api_key: os.environ/AZURE_API_KEY
      api_version: os.environ/AZURE_API_VERSION
      api_base: os.environ/AZURE_API_BASE
      rpm: 6

  - model_name: gpt-4
    litellm_params:
      model: azure/gpt-4-ca
      api_base: https://my-endpoint-canada-berri992.openai.azure.com/
      api_key: os.environ/AZURE_API_KEY
      rpm: 6

  - model_name: claude-opus
    litellm_params:
      model: anthropic/claude-3-opus-20240229
      api_key: os.environ/ANTHROPIC_API_KEY

router_settings:
  fallbacks: [{"gpt-3.5-turbo": ["gpt-4"]}]
  context_window_fallbacks: [{"gpt-3.5-turbo": ["gpt-4"]}]
  content_policy_fallbacks: [{"gpt-3.5-turbo": ["claude-opus"]}]
  enable_pre_call_checks: true   # required for context window enforcement
  num_retries: 3
  allowed_fails: 3
  cooldown_time: 30

Chain execution order

1. Request hits gpt-3.5-turbo
2. Fails → retried num_retries times within the same model group (using order-based priority if set)
3. Still failing → router checks the fallbacks list and tries gpt-4
4. If the error was a ContextWindowExceededError, context_window_fallbacks is used instead
5. If the error was a ContentPolicyViolationError, content_policy_fallbacks is used instead

enable_pre_call_checks: true adds a pre-flight check that filters out deployments whose context window is smaller than the incoming message - before the API call is even made.

---

Cost Routing: Route to the Cheapest Model Automatically

Cost-based routing sends each request to the deployment with the lowest cost per token at that moment. It's one of the simplest levers in a broader toolkit for cutting your LLM API costs.

The formula is simple:

cost = (input_tokens × input_cost_per_token) + (output_tokens × output_cost_per_token)

LiteLLM looks up pricing from its internal model_prices_and_context_window.json. If a deployment isn't in that map, it defaults to $1 per request - so it'll be deprioritized automatically.

Code example with custom pricing

import os
import asyncio
from litellm import Router

model_list = [
    {
        "model_name": "my-model",
        "litellm_params": {
            "model": "gpt-4o",
            "api_key": os.getenv("OPENAI_API_KEY"),
            "input_cost_per_token": 0.000005,    # $5 per 1M input tokens
            "output_cost_per_token": 0.000015,   # $15 per 1M output tokens
        },
        "model_info": {"id": "openai-gpt4o"},
    },
    {
        "model_name": "my-model",
        "litellm_params": {
            "model": "claude-haiku-20240307",
            "api_key": os.getenv("ANTHROPIC_API_KEY"),
            "input_cost_per_token": 0.00000025,  # $0.25 per 1M input tokens
            "output_cost_per_token": 0.00000125, # $1.25 per 1M output tokens
        },
        "model_info": {"id": "claude-haiku"},
    },
    {
        "model_name": "my-model",
        "litellm_params": {
            "model": "gemini/gemini-1.5-flash",
            "api_key": os.getenv("GEMINI_API_KEY"),
            # Uses LiteLLM's built-in pricing from model_prices_and_context_window.json
        },
        "model_info": {"id": "gemini-flash"},
    },
]

router = Router(model_list=model_list, routing_strategy="cost-based-routing")

async def main():
    response = await router.acompletion(
        model="my-model",
        messages=[{"role": "user", "content": "Summarize this document."}],
    )
    print(response)
    print("Picked deployment:", response._hidden_params["model_id"])
    # Expect claude-haiku or gemini-flash - whichever is cheapest

asyncio.run(main())

Practical tip: This strategy shines when you're mixing GPT-4o (expensive) with Claude Haiku (~20× cheaper on input tokens) or Gemini Flash. Routine queries - summarization, classification, simple Q&A - can be routed to the cheaper model automatically, without changing a line of application code. The flip side: reserve your most capable tier for the queries that truly need it - see when routing to reasoning models for hard tasks actually pays off.

Note that cost-based-routing is async only - use router.acompletion(), not router.completion().

---

Routing Groups: Apply Different Strategies Per Model

Routing groups let you assign different LiteLLM routing strategies to different model groups within the same router - without spinning up a second instance.

The classic use case: latency-based routing for your expensive gpt-4o calls, but plain simple-shuffle for cheap utility models. (For routing logic driven by query signals rather than deployment health, see advanced signal-driven routing patterns.)

Rules:

• Each model_name can belong to at most one group. Overlap raises a ValueError at init.
• Models not in any group use the top-level routing_strategy (the implicit default group).
• The name "default" is reserved.
• Groups can be updated at runtime via Router.update_settings(routing_groups=[...]).

Python SDK example

from litellm import Router

router = Router(
    model_list=[
        {"model_name": "gpt-4o", "litellm_params": {"model": "openai/gpt-4o", "api_key": "..."}},
        {"model_name": "gpt-4o", "litellm_params": {"model": "azure/gpt-4o", "api_base": "...", "api_key": "..."}},
        {"model_name": "gpt-4o-mini", "litellm_params": {"model": "openai/gpt-4o-mini", "api_key": "..."}},
    ],
    routing_strategy="simple-shuffle",   # default for ungrouped models
    routing_groups=[
        {
            "group_name": "latency-sensitive",
            "models": ["gpt-4o"],
            "routing_strategy": "latency-based-routing",
            "routing_strategy_args": {"ttl": 3600},
        },
    ],
)

Proxy YAML equivalent

router_settings:
  routing_strategy: simple-shuffle   # fallback for ungrouped models
  routing_groups:
    - group_name: hot-path
      models: [gpt-4o, claude-sonnet]
      routing_strategy: latency-based-routing
      routing_strategy_args:
        ttl: 60           # short window - react quickly to latency spikes

    - group_name: batch
      models: [gpt-4o-mini, llama-70b]
      routing_strategy: usage-based-routing-v2
      routing_strategy_args:
        rpm: 10000

Result: gpt-4o uses latency-based routing across OpenAI + Azure deployments. gpt-4o-mini uses the top-level simple-shuffle.

---

Production Tips: Cooldowns, Retries & Redis

Cooldowns

Cooldowns apply to individual deployments, not entire model groups. When a deployment crosses the failure threshold, it's temporarily removed from the pool while healthy alternatives keep serving requests.

Default values (from constants.py):

• allowed_fails: 3 failures per minute before cooldown
• cooldown_time: 5 seconds

Automatic cooldown triggers:

Condition	Trigger	Duration
Rate limit (429)	Immediate	5s default
High failure rate	>50% failures in current minute	5s default
Non-retryable errors	401, 404, 408	5s default

router = Router(
    model_list=model_list,
    allowed_fails=3,       # cooldown after 3 failures/min
    cooldown_time=30,      # stay cooled down for 30 seconds
)

Retries

LiteLLM supports both fixed and exponential backoff retries:

router = Router(
    model_list=model_list,
    num_retries=3,
    retry_after=5,   # wait at least 5s before retrying (for RateLimitErrors, exponential backoff applies)
)

For fine-grained control, use RetryPolicy to set different retry counts per error type:

from litellm.router import RetryPolicy, AllowedFailsPolicy

retry_policy = RetryPolicy(
    RateLimitErrorRetries=3,
    ContentPolicyViolationErrorRetries=3,
    AuthenticationErrorRetries=0,   # don't retry auth errors - they won't self-heal
    TimeoutErrorRetries=2,
)

Redis for distributed deployments

In a multi-instance deployment (Kubernetes, auto-scaling), you need Redis to share cooldown state and TPM/RPM tracking across all router instances:

router = Router(
    model_list=model_list,
    routing_strategy="simple-shuffle",
    redis_host=os.environ["REDIS_HOST"],
    redis_password=os.environ["REDIS_PASSWORD"],
    redis_port=os.environ["REDIS_PORT"],
    cache_responses=True,
)

Or in your proxy config.yaml:

router_settings:
  routing_strategy: simple-shuffle
  redis_host: <your-redis-host>
  redis_password: <your-redis-password>
  redis_port: 6379
  enable_pre_call_checks: true

Max parallel requests

Use max_parallel_requests to cap concurrent calls per deployment - critical for preventing a single deployment from getting hammered during traffic spikes:

# Per deployment
model_list = [{
    "model_name": "gpt-4",
    "litellm_params": {
        "model": "azure/gpt-4",
        "api_key": os.getenv("AZURE_API_KEY"),
        "max_parallel_requests": 10,   # max 10 concurrent calls to this deployment
    },
}]

# Or set a global default
router = Router(model_list=model_list, default_max_parallel_requests=20)

Pre-call checks

enable_pre_call_checks=True filters out deployments before the API call based on:

1. Context window - skips deployments whose limit is smaller than the incoming message
2. Region - skips deployments outside a required region (e.g., EU-only)

This pairs with context_window_fallbacks to route long prompts to larger-context models automatically, with zero provider API calls wasted on requests that would fail anyway.

---

Key Takeaways

• simple-shuffle is the right default for most production workloads - lowest latency overhead, no Redis dependency.
• Model pools group multiple deployments under one alias; use weight, rpm/tpm, and order to control traffic distribution and priority.
• Three fallback types cover different failure modes: fallbacks (general), content_policy_fallbacks, and context_window_fallbacks - all models referenced must be in model_list.
• cost-based-routing is async-only and automatically picks the cheapest deployment - ideal when mixing GPT-4o with Claude Haiku or Gemini Flash.
• Routing groups let you assign per-model strategies (e.g., latency-based for gpt-4o, simple-shuffle for gpt-4o-mini) without running multiple routers.
• Cooldowns isolate individual deployments, not entire model groups - healthy peers keep serving while a failing one recovers.
• Redis is required for multi-instance deployments to share cooldown state and rate limit tracking across router instances.

---

FAQ

What is the LiteLLM Router and what does it do?

The LiteLLM Router is a Python class (from litellm import Router) that load-balances requests across multiple LLM deployments. It handles retries, cooldowns, fallbacks, and cost tracking automatically. You define a model_list with your deployments, initialize the router, and call router.completion() or router.acompletion() exactly like the OpenAI SDK.

What is the difference between fallbacks, context_window_fallbacks, and content_policy_fallbacks?

They target different error types. fallbacks catches general errors like 429 rate limits and 500 server errors. context_window_fallbacks triggers specifically when the input exceeds a model's token limit - requires enable_pre_call_checks: true. content_policy_fallbacks triggers on ContentPolicyViolationError, letting you route flagged content to a different provider (e.g., from Azure OpenAI to Anthropic). You can configure all three simultaneously.

How does LiteLLM cost routing work?

With routing_strategy="cost-based-routing", the router calculates (input_tokens × input_cost_per_token) + (output_tokens × output_cost_per_token) for each healthy deployment and picks the cheapest one. Pricing comes from LiteLLM's built-in model_prices_and_context_window.json, or you can override it per deployment with input_cost_per_token and output_cost_per_token in litellm_params. Deployments not found in the price map are assigned a cost of $1 and deprioritized.

When should I use routing groups?

Use routing groups when different models in the same router need different strategies. For example: gpt-4o with latency-based-routing (because users are waiting) and gpt-4o-mini with simple-shuffle (because it's a background batch job). Without routing groups, you'd need to run two separate router instances. Each model_name can belong to at most one group - overlap raises a ValueError at initialization.

Do I need Redis for the LiteLLM Router?

Not for single-instance deployments. Redis becomes necessary when you're running multiple LiteLLM Proxy instances (e.g., in Kubernetes with horizontal scaling) and need to share cooldown state, TPM/RPM tracking, and response caching across all instances. Without Redis in that scenario, each instance tracks state independently and you'll get inconsistent rate limit behavior.

---

Useful Sources

• LiteLLM Router Docs - Load Balancing & Routing Strategies
• LiteLLM Proxy - Load Balancing
• LiteLLM Proxy - Fallbacks & Reliability
• BerriAI/litellm on GitHub
• LiteLLM Model Prices & Context Window JSON
